Fab Tractor Lawn Mower - 22HP Kohler | MTD

Primary Function

The MTD 274107 operates as a commercial-grade ride-on mower engineered for maintaining expansive residential estates and light commercial grounds. Driven by a 22 hp Kohler twin-cylinder engine, it delivers sustained rotational force across grades, positioning it among reliable heavy duty riding lawn mower systems for property owners needing consistent clip quality without stalling on inclines. Smooth directional control depends on a cable-guided hydrostatic pedal that eliminates traditional gear changes and enables precise low-speed navigation around ornamental borders, pool decks, and fence lines.

Materials & Safety

Chassis durability relies on a fully robotically welded steel framework combined with a solid cast iron front axle to absorb vibration during prolonged towing or rough traverse operations. The mowing profile is produced by a 117 cm reinforced fabricated steel housing containing two balanced shear pins, which directs airflow upward for complete stalk severance and equalized debris distribution. Operator protection includes a positive-type electric blade engagement toggle that severs drive power immediately upon deactivation, a mandated backup signal circuit for reverse travel, and four polyurethane anti-scalp rollers to preserve soil integrity on rolling topography. Preventative upkeep is facilitated by an external translucent fuel indicator and a factory-installed hose connector beneath the deck for hydraulic spray cleaning.

Specifications

• Deck Width: 117 cm (46 inches) • Engine Architecture: Kohler 22 hp Twin Cylinder • Drive System: Cable-Actuated Hydrostatic • Height Control: 12-Point Spring-Assisted Mechanical Lever • Cutter Actuation: Independent Electric Clutch • Maneuvering Sweep: 40.6 cm • Tire Dimensions: 38.1 × 15.2 cm (Front) / 50.8 × 20.3 cm (Rear) • Operating Mass: 272.2 kg • Operator Accommodation: Adjustable High-Back Bench with Locking Cruise Control • Production Region: United States

Horse Power	22 hp
Size	117 cm
Country of Origin	USA
Weight	272.2 kg
Brand	MTD
Model Number	274107
Engine Brand	Kohler
Engine Type	Twin Cylinder
Transmission	Foot-Operated Hydrostatic
Deck Material	Reinforced Fabricated Steel
Number of Blades	2
Blade Engagement	Electric
Deck Height Adjustment	12-Position, Spring-Assisted
Anti-Scalp Wheels	2 Front, 2 Rear
Front Axle	Cast Iron
Frame	Fully Robotically Welded
Turning Radius	40.6 cm
Front Tires	38.1 cm x 15.2 cm
Rear Tires	50.8 cm x 20.3 cm
Seat	Adjustable High Back
Cruise Control	Yes
Deck Wash System	Integrated
Fuel Gauge	Exterior Sight Gauge

Frequently asked questions What type of transmission does this lawn tractor have? It features a foot-operated hydrostatic transmission, which provides smooth and easy speed control without the need for manual shifting. What is the cutting width of the mower deck? The cutting deck is 117 cm wide and is made of reinforced fabricated steel with twin blades for efficient mowing. How is the cutting height adjusted? The cutting height is adjusted using a twelve-position, spring-assisted lever, allowing you to easily customize the cut to your lawn's needs. What comfort features are included for the operator? The tractor includes an adjustable high-back seat for support and a cruise control feature to maintain a consistent speed, reducing fatigue during long mowing sessions.
